What is the minimum number of receptacle outlets required in a house?
Tuesday, November 26, 2019
The total number varies, of course, based on the size of the house. But here are the minimums for each area, per National Electrical Code (NEC 210.50):
• One receptacle at front and back of house exterior, not more than 6.5-feet above grade [210.52(E)]
• Receptacles in "every kitchen, family room, dining room, living room, parlor, library, den, sunroom, bedroom, recreation room, or similar room" must be located so that no point along any wall that has an unbroken length of 2-feet or more is more than 6-feet from a receptacle [210.52(A)(1)].
• Kitchen wall countertop receptacles must be located so that no point along the counter is more than 2-feet from a receptacle. Minimum one receptacle for each peninsula or island countertop. For more details, go to our blog post How far apart should the electrical receptacles be placed? Two dedicated 20-amp circuits are required to serve the kitchen, pantry, breakfast room, dining room, or similar areas [210.52(B)].
• One receptacle for hallway that is 10-feet or longer [210.52(H)].
• One receptacle within 3-feet of each bathroom sink [210.52(D)].
• One receptacle in laundry area for laundry equipment [210.52(F)]
• Foyers that are not part of a hallway and more 60 square feet must have a receptacle on each wall more than 3-feet in width
• Balconies, decks, or porches that are accessible from inside the home must have one receptacle {210.52(E)(3)].
• One receptacle for each vehicle bay in a garage [210.52(G)(1)].
• One receptacle in each unfinished basement [210.52(G)(3)]
• One receptacle for servicing any heating, air conditioning, or refrigeration equipment, located within 25-feet of each unit.
A floor receptacle outlet cannot be counted towards the minimum requirements, either for spacing between receptacles or minimum number of receptacles per area, unless the floor receptacle is within 18 inches of the wall, per National Electrical Code [NEC 211.52(A)(3)]. Also, receptacles in wet areas, such as exterior, kitchen, garage, and bathrooms, must have GFCI protection. See our blog post Where are GFCI receptacle outlets required? for more details. For the locations and timeline for where AFCI protection is required for receptacles, go to our blog post When did arc fault circuit interrupter (AFCI) breakers first become required?
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
