How do I find the size in tons of an Oxbox air conditioner or heat pump?

Wednesday, October 12, 2022

The size in tons of an Oxbox air conditioner or heat pump is determined from the third and fourth numbers in a series of four numbers at the center of the model number.  They will be divideable by 6 or 12 and, since a ton of cooling equals 12,000 BTU, dividing that number by 12 will give the tonnage of the unit. So J4AC3036B1000AA indicates 3 tons, and J4AC6024B1000AA means 2 tons.

    Here’s a rundown of the range you will likely encounter: 18 = 1.5 tons, 24 = 2 tons, 30 - 2.5 tons, 36 = 3 tons, 42 = 3.5 tons, 48 = 4 tons, and 60 = 5 tons.

   If you are unsure whether you have found the right two numbers, you can double-check it by looking for the “RLA” rating on the data plate. RLA is an acronym for Rated Load Amperage, and is what the maximum amperage should be when the condenser up and running. If you divide the RLA by 6 for older units and 5 or 6 for newer units, you should get a number that approximates (not exactly) the tonnage of the system. Make sure you use RLA and not LRA, Locked Rotor Amperage, which is the surge of amps necessary to overcome inertia and start the system. It averages around five times the RLA.    To determine the age of an Oxbox system, go to our blog post How to I find the age of an Oxbox air conditioner or heat pump? For the age of another brand or manufacturer, go to our blog post How do I determine the age of my air conditioner?

      And to figure out what all the other numbers listed on the condenser data plate mean, go to our blog post How do I understand the air conditioner or heat pump condenser label (data plate)?
