What is the minimum trap seal depth under a sink drain?
Sunday, June 19, 2022
The minimum trap seal depth is 2-inches according to the International Residential Code (IRC P3201.2). A trap seal is the standing water in the U-shaped pipe under a sink that keeps sewer gas from traveling backwards through the drain piping and up through the sink into a home. It is measured as shown in the diagram below. Two problems are created when the trap seal is less than 2-inches: the trap water is more likely to be siphoned away during normal usage by the suction created downstream in the pipe, and the trap seal is more susceptible to loss by evaporation.
The maximum trap seal depth is 4-inches, and traps that are not installed by a professional plumber are more likely to have too much trap seal rather than not enough. Excessive trap depth slows drainage and is more easily clogged.
• • • • • • • • • • • • • • • • • • • • •
Field Guide for Home Inspectors, a quick reference for finding the age of 154 brands of HVAC systems, water heaters, and electrical panels, plus 210 code standards for site-built and manufactured homes, and the life expectancy rating of 195 home components. Available at amazon.com for $19.95.
• • • • • • • • • • • • • • • • • • • • • •
Here’s links to more articles about PLUMBING TRAPS:
• What are the code requirements for layout of drain piping under sinks?
• Why is it a problem when a trap under a sink is installed backwards?
• What is a double trap in plumbing?
• What types of plumbing traps are illegal by code?
• What is bell trap at a plumbing drain?
• What is an "S-Trap" under my sink? Why is it a problem?
• How do I get rid of the sewer gas smell in my house?
• What is the minimum and maximum distance a P-trap can be below a sink?
• Why is the European-style bottle trap not approved by the plumbing codes in the U.S.?
• Can I make a trap under the sink from straight pipe and 90º elbows?
• What is a drum trap at a plumbing drain?
Trap seal diagram - CodeCheck
